Brief introduction
1. This instrument is mainly used to measure the thickness of various textiles and textile products under different pressures, and can also be used to measure the thickness of other uniform thin materials.
2. Applicable standard: GB/T3820.
Main technical indicators of the instrument
1. Test thickness range: 0.01mm~25.00mm;
2. Minimum dividing value: 0.01mm;
3. Presser foot diameter and area: Φ 11.28mm Φ 50.48mm Φ 56.42mm Φ 112.84mm
100mm2 2000mm2 2500mm2 10000mm2
4. Weight: 5cN, 10cN, 50cN, 100cN, 200cN and 500cN;
5cN Weights |
only |
1 |
10cN Weights |
only |
2 |
50cN Weights |
only |
2 |
100cN Weights |
only |
1 |
200cN Weights |
only |
2 |
500cN Weights |
only |
2 |
5. Weight pressing time: 10s, 30s;
6. Power supply: AC220V ± 10% 50Hz;
7. Net volume: 410mm × 160mm × 395mm;
8. Net weight: 25kg.
