It is mainly used for winding the skein of cotton, wool, hemp, chemical staple fiber and blended yarn into package yarn for cylinder dyeing, warping, knitting, wool weaving and other processes!
Technical parameters
Copper pipe specification: 6 * (170mm)
Structure: double/single machine, each (12-96) ingots, customizable
Power supply: three-phase 380V 50/60HZ or V220
Drive: single spindle independent motor drive (AC/DC)
Power consumption: 90W/ingot
Forming bobbin: round column/cone (mesh tube)
Yarn speed range: 300-1000m/min
Fixed length device: PLC centralized control/display
Yarn breaking automatic stop device: electronic yarn breaking automatic stop
Speed regulation device: frequency conversion speed regulation
Electronic anti overlap device: standard configuration
Complete machine lighting device: standard configuration
Electronic yarn cleaning device (detecting yarn quality): optional
Air splicer (yarn without knot): optional
Air blowing and suction cleaner (dust removal): optional
Precision weighing device (electronic scale/spindle): optional
Special customization: 2 spindles, 4 spindles, 6 spindles, 8 spindles,
