Main technical indicators of the instrument
1. Test thickness range: 0.01mm~25.00mm;
2. Minimum dividing value: 0.01mm;
3. Presser foot diameter and area: Φ 11.28mm Φ 50.48mm Φ 56.42mm Φ 112.84mm
100mm2 2000mm2 2500mm2 10000mm2
4. Weight: 5cN, 10cN, 50cN, 100cN, 200cN and 500cN;
5cNWeights |
only |
1 |
10cN Weights |
only |
2 |
50cN Weights |
only |
2 |
100cN Weights |
only |
1 |
200cN Weights |
only |
2 |
500cN Weights |
only |
2 |
5. Weight pressing time: 10s, 30s;
6. Power supply: AC220V ± 10% 50Hz;
7. Net volume: 410mm × 160mm × 395mm;
8. Net weight: 25kg.
