Main features:
1. The instrument is controlled by a microcomputer. The touch screen inputs and displays data, guided by the interface, and completes the time, temperature setting and standard selection. It can control the drainage and time reset, correct the time and date, adjust the brightness of the display screen, view the temperature time curve, and achieve inching and running, and stop the control. Simple operation, clear at a glance.
2. The dry burning prevention function is equipped with a contactless inductive switch. In case of water shortage, the heating function will not start, effectively protecting the instrument from burning.
3. Motor thermal protection function: for long-term continuous work reaching the set temperature, the motor will enter the protection state, stop working, and resume working until the temperature drops, effectively avoiding unnecessary fault losses.
4. When the time comes, the alarm reminder function will display the reminder when the set time is reached, and the buzzer will give an alarm.
5. The transmission shaft of this machine is straight through type. The fixed ends are all made of stainless steel waterproof bearings, which will not overflow. The double belt drive is used to make the inching action soft when loading and unloading the test cup, and the noise is low during the operation of the test process.
6. The sample cup holder of this machine can be of composite type, which can respectively load 550ml cup and 1200ml cup, and is made of stainless steel.
7. The machine shell, working room and control box shell are made of 304 stainless steel, which is beautiful and corrosion resistant.
8. Four universal adjustable feet, stable and firm
9. All stainless steel positioning hinge, the preset opening angle of the upper cover is reasonable, and it will not fall back automatically.
10. The machine is equipped with a drainage pump, which can place the downpipe at the outlet pipe for a long time. Just press "Drainage" on the touch screen to complete the operation. The operation is simple and saves the tedious work of supporting downpipes.
11. Applicable standards: national standards GB/T3921.15, GB/T5711, American standards: ATCC61, etc
12. Special reminder: The cup holder rotates counterclockwise. If it rotates clockwise after power on, please adjust the power supply.
Main test functions:
It is applicable to the washing fastness test of cotton, wool, silk, hemp, chemical fiber and blended, printed and dyed textiles, as well as the test to assess the washing fastness performance of dyes, for the use of printing and dyeing industry, dye industry, textile quality inspection departments and scientific research institutions.
This machine complies with national standards GB/T3921.15, GB/T5711, American standards: ATCC61, etc.
Main indicators and data of the instrument
1. Sample cup volume: 550mL ± 50mL 12 pieces
2. Rotating speed of rotating frame: 40r/min ± 2r/min
3. Motor: 180W 380V
4. Drainage pump power: 30W
5. Heating power: 5000W/working room.
6. Preset time: 0.1min~9999min
7. Power supply: AC three-phase 380V ± 10% 50Hz
