Working principle:
The ultrasonic industrial humidifier uses the electronic ultra frequency oscillation (the oscillation frequency is 1.7MHz). Through the high-frequency resonance of the atomizer, the water is thrown off the water surface to produce a naturally flowing water mist. 1-5 μ m water particles are generated without heating or chemical agents to float in the air, so as to improve the relative humidity of the air.
Operating conditions of ultrasonic humidifier:
1. Ambient temperature: normal working ambient temperature is 0-40 ° C
2. Water source: clean and neutral tap water
Features of ultrasonic humidifier:
1. The ultrasonic humidifier adopts an integrated atomization module, which can replace chips, and is easy to maintain and operate on site
2. The ultrasonic humidifier has high humidification efficiency (nearly 100%), high humidification intensity, small and uniform fog particles, and can quickly reach the required relative humidity
3. The integrated atomizing movement has its own water overflow protection device, which can effectively ensure that the atomizing movement will automatically stop working when the water level is too low, without additional equipment, saving costs
4. The control mode of ultrasonic humidifier is flexible and convenient, and the humidity is automatically controlled.
5. Digital automatic control of humidity. The control system is equipped with imported humidity sensor, which has high control accuracy and rapid response. Continuous work after setting, without the need for personnel
6. The ultrasonic humidifier is made of stainless steel box, with beautiful appearance, corrosion resistance and long service life
7. The equipment is equipped with high-performance automatic water filling solenoid valve, overflow port and drain port, which are easy to use, safe and reliable
8. After repeated tests and years of actual testing, the ultrasonic humidifier has a compact structure and reasonable collocation. No noise during operation, high atomization effect on liquid
Function of ultrasonic humidifier:
Textile industry: increasing temperature and humidity, moisturizing, temperature control, eliminating static electricity, reducing dust, cutting ends, no defects, no parking, no piling, no trucks, greatly increasing efficiency, reducing flying, roughness, fiber vulnerability and other problems. Revival, weight gain, yield increase and income increase.
Main parameters:
Humidification amount: 24kg/h
Voltage regulation: 220V-50HZ
Rated power: 1200W
Humidity regulation: 10% - 99% RH
Control accuracy: ± 3% RH
Fog outlet: 110MM (2 PVC pipes)
Weight: 42kg
Body size: 700 × four hundred and fifty × 430mm
Fuselage protection measures: water shortage protection, overflow protection
Control mode: fully automatic
Applicable area: 160-190 ㎡
Applicable industries of ultrasonic humidifier:
Textile industry: roving, spinning, weaving, non-woven, folding machine, double twister, ribbon, wool spinning, cotton spinning, chemical fiber, blending, flocking, weaving and dyeing, twine, flax, silk weaving, knitting, etc
Electronics industry: SMT workshop, LCD factory, PSB factory, ICM pilot factory, packaging factory, semi conductive component factory, etc
Printing industry: paper printing, pattern printing, glass printing, fine printing, special printing, screen printing, transfer printing, etc
Spraying industry: automobile coating plants, mobile phones, televisions, refrigerators, air conditioners, computers and other household appliances and various industrial products
Tobacco industry: tobacco grading plant, storage warehouse, puffed cut tobacco moisture recovery workshop, etc
Edible fungi: Flammulina velutipes, Ru Ru, Ru Ru, Ru Xiangru, Ru Shuangspora, etc
Computer room: management control room, switch room, server room, computer room, Internet cafe, launch station, customer service center, etc.
Supermarket fresh-keeping: green leafy vegetables, fruits, fresh meat, fresh food, refrigerated display cabinets, air coolers, bread cabinets, etc.
Laboratory: various inspection, testing, quality, analysis, laboratory and other constant temperature environments.
Gunpowder industry: gunpowder production, filling, manufacturing, storage, etc.
Automobile industry: coating plant, assembly plant, film workshop, glass printing, flocking, exhibition hall, etc
Food industry: fresh keeping of dried and dehydrated food (kelp, vermicelli), steamed bread, bread, fruits and vegetables under constant humidity, storage, transportation, etc
Planting: edible fungi, various orchids, tropical plants, soilless cultivation, flower houses, etc
Breeding industry: large-scale breeding places for livestock, birds, insects, etc
Artificial landscape: tropical artificial rain, film and television, exhibition, park, zoo, square, water screen film, etc
Health care: bath, fitness, skin care, beauty, cold fog bath, salt fog bath, negative ion bath, etc
Bar: pure draft beer+real ice+natural and elegant water smoke
Air conditioning industry: airports, stations, hotels, shopping malls, hospitals, cinemas, office buildings, etc
Plastic industry: plastic injection molding plants, plastic product manufacturers, etc.
Fruit industry: bananas, oranges, etc
Steel industry: special for crown block industry
