name |
effect |
remarks |
Air compressor |
Power source, providing clean air |
Compulsory |
Pre water filter |
Automatically remove impurities in water |
Self matching or optional |
Oil filter |
Filter oil, water and other impurities in compressed air |
|
Temperature and humidity sensor of computer control system |
Automatically maintain the specified temperature and humidity |
Related parameters
1. Performance parameters (this table is a set of standard data)
Parameters of different spray nozzles under the condition of 2 bar water pressure and air pressure |
|||||
Nozzle model |
Spray volume(L/h) |
Air consumption(m3/min) |
Spray distance(m) |
Spray particles(m) |
Droplet arrival area(m) |
1 |
11 |
≈0.150 |
12-15 |
5-10 |
150-200 |
2 |
13 |
≈0.150 |
12-15 |
20-30 |
150-200 |
3 |
18 |
≈0.150 |
12-15 |
40-60 |
150-200 |
